Carbide inserts are replaceable and usually indexable bits of cemented carbide used in machining steels, cast iron, high temperature alloys, and nonferrous.Choose from our selection of internal grooving tool in a wide range of styles and sizes. In stock and ready to ship.
Carbide inserts and cutting tools matching internal grooving tool, in stock and ready to ship.
Excellent anti-built-up features and chipping resistance, suitable for semi-finishing and finishing of steel parts. 1. High impact resistance, excellent adhesion, reduced friction. 2. Superior wear protection, temperature and oxidation stability. 3. Provides perfect turning surface of the workpiece . 4. Less tool breakage, Long tool life. 5. A reliable and secure performance every time.
1. Consistent Performance : JDMW inserts are designed to maintain high precision during machining, providing consistent results across different workpieces. 2. Multiple Applications : Suitable for a wide range of materials including steel, stainless steel, cast iron, and non-ferrous materials. 3. Various Cutting Conditions : Effective in both roughing and finishing operations, making them versatile for different mach...
1. All raw materials are tested in terms of density, hardness and T.R.S before use. 2. Every piece of product goes through in-process and final inspection. 3. Every batch of product can be traced.
1. Ultrafine cemented carbide 2. Nice chip breaker 3. Durable wear-resistance 4. Good surface soomthness
1. Made from 100% virgin raw material; 2. Produced with advanced equipment and process; 3. All products go through in-process and final inspection; 4. Free online technical service available; 5. Stable and continuous production ability.
1. High impact resistance, excellent adhesion, reduced friction. 2. Superior wear protection, temperature and oxidation stability. 3. Provides perfect turning surface of the work piece . 4. Less tool breakage, Long tool life. 5. A reliable and secure performance every time
● Durability and Quality ● CNC precision machining ● High working efficiency
1.Easy to use and handle 2.Excellent hole straightness and surface finish 3.Reliable performance 4.Productivity in a wide application range
1. 100% new materials 2. Product model rich 3. Wear resistant 4. High quality and best price 5. OEM service
1. Made from 100% virgin raw material; 2. Produced with advanced equipment and process; 3. All products go through in-process and final inspection; 4. Free online technical service available; 5. Stable and continuous production ability.
Round Carbide Inserts : Multi-directional Cutting : Round inserts usually feature multiple cutting edges, allowing for versatile use in different directions, which increases their lifespan and flexibility. Long Tool Life : The carbide material is highly wear-resistant, maintaining stable performance under high heat and pressure, thus extending tool life. Versatility : Round inserts are suitable for various machining ...
Our carbide inserts sold very well in the domestic market and Europe,South America,Turkish, Indian market. It is the best quality, low price. We can satisfy all customers requirements.
Dimension ISO L I.C S d r WNMG060404-CM 6.50 9.525 4.76 3.81 0.40 WNMG060408-CM 6.50 9.525 4.76 3.81 0.80 WNMG060412-CM 6.50 9.525 4.76 3.81 1.20 WNMG080404-CM 8.70 12.70 4.76 5.16 0.40 WNMG080408-CM 8.70 12.70 4.76 5.16 0.80 WNMG080412-CM 8.70 12.70 4.76 5.16 1.20 CVD Coated Cemented Carbide Grade Description Equivalentto ISO YC1015 MT-CVD coated, the substrate with exce lent wear resistance in com bination with MT-...
Dimension ISO L I.C S d r CNMG120404-CM 12.90 12.70 4.76 5.16 0.40 CNMG120408-CM 12.90 12.70 4.76 5.16 0.80 CNMG120412-CM 12.90 12.70 4.76 5.16 1.20 CNMG160608-CM 16.10 15.875 6.35 6.35 0.80 CNMG160612-CM 16.10 15.875 6.35 6.35 1.20 CNMG190612-CM 19.30 19.05 6.35 7.94 1.20 CNMG190616-CM 19.30 19.05 6.35 7.94 1.60 CNMG190624-CM 19.30 19.05 6.35 7.94 2.40 Grades Description CVD coated cemented carbide Grade Description...
Dimension ISO L I.C S d r TNMG160404-CM 16.50 9.525 4.76 3.81 0.40 TNMG160408-CM 16.50 9.525 4.76 3.81 0.80 TNMG160412-CM 16.50 9.525 4.76 3.81 1.20 TNMG220408-CM 22.00 12.70 4.76 5.16 0.80 TNMG220412-CM 22.00 12.70 4.76 5.16 1.20 CVD Coated Cemented Carbide Grade Description Equivalentto ISO YC1015 MT-CVD coated, the substrate with exce lent wear resistance in com bination with MT-TiCN, fine grained AL 2 O 3 TiN mul...
Dimension ISO L I.C S d r CNMG120404-MA 12.90 12.70 4.76 5.16 0.40 CNMG120408-MA 12.90 12.70 4.76 5.16 0.80 CNMG120412-MA 12.90 12.70 4.76 5.16 1.20 CNMG160608-MA 16.10 15.875 6.35 6.35 0.80 CNMG160612-MA 16.10 15.875 6.35 6.35 1.20 CNMG190612-MA 19.30 19.05 6.35 7.94 1.20 CNMG190616-MA 19.30 19.05 6.35 7.94 1.60 CNMG190624-MA 19.30 19.05 6.35 7.94 2.40 PVD Coated Cemented Carbide Grade Description YP3015 2-4um TiALN...
Dimension ISO L I.C S d r CNMM190616- HY 19.30 19.05 6.35 7.94 1.20 CNMM190624- HY 19.30 19.05 6.35 7.94 1.60 CNMM250924-HY 25.79 25.40 9.525 9.12 2.40 CNMM250932-HY 25.79 25.40 9.525 9.12 3.20 Our Advantages 1.Cutting edge inclination designation is good to control chip flow direction and obtains excellent surface quality 2.sharp cutting edge, small cutting force 3.good machining surface quality 4.special chipbreake...
Dimension ISO L I.C S d r CNMG120404-TM 12.90 12.70 4.76 5.16 0.40 CNMG120408-TM 12.90 12.70 4.76 5.16 0.80 CNMG120412-TM 12.90 12.70 4.76 5.16 1.20 CNMG160608-TM 16.10 15.875 6.35 6.35 0.80 CNMG160612-TM 16.10 15.875 6.35 6.35 1.20 CNMG190612-TM 19.30 19.05 6.35 7.94 1.20 CNMG190616-TM 19.30 19.05 6.35 7.94 1.60 CNMG190624-TM 19.30 19.05 6.35 7.94 2.40 CNMG250924-TM 25.79 25.40 9.525 9.12 2.40 CNMG250932-TM 25.79 25...
Dimension ISO L I.C S d r TNMG160404-TM 16.50 9.525 4.76 3.81 0.40 TNMG160408-TM 16.50 9.525 4.76 3.81 0.80 TNMG160412-TM 16.50 9.525 4.76 3.81 1.20 TNMG220408-TM 22.00 12.70 4.76 5.16 0.80 TNMG220412-TM 22.00 12.70 4.76 5.16 1.20 Grades Description CVD coated cemented carbide Grade Description Equivalent to ISO YC1015 MT-CVD coated, the substrate with excellent wear resistance in combination with MT-TiCN,fine graine...
Dimension ISO L I.C S d r DNMG110404-TM 11.60 9.525 4.76 3.81 0.40 DNMG110408-TM 11.60 9.525 4.76 3.81 0.80 DNMG110412-TM 11.60 9.525 4.76 3.81 1.20 DNMG150404-TM 15.50 12.70 4.76 5.16 0.40 DNMG150408-TM 15.50 12.70 4.76 5.16 0.80 DNMG150412-TM 15.50 12.70 4.76 5.16 1.20 DNMG150604-TM 15.50 12.70 6.35 5.16 0.40 DNMG150608-TM 15.50 12.70 6.35 5.16 0.80 DNMG150612-TM 15.50 12.70 6.35 5.16 1.20 Grades Description CVD co...
Dimension ISO L I.C S d r SNMG120404-CM 12.70 12.70 4.76 5.16 0.40 SNMG120408-CM 12.70 12.70 4.76 5.16 0.80 SNMG120412-CM 12.70 12.70 4.76 5.16 1.20 SNMG150608-CM 15.875 15.875 6.35 6.35 0.80 SNMG150612-CM 15.875 15.875 6.35 6.35 1.20 SNMG190612-CM 19.05 19.05 6.35 7.94 1.20 SNMG190616-CM 19.05 19.05 6.35 7.94 1.60 SNMG190624-CM 19.05 19.05 6.35 7.94 2.40 PVD Coated Cemented Carbide Grade Description YP3015 2-4um TiA...
1. Excellent wear resistance and breakage resistance 2. Professional inspection and high precision 3. High precision, easy replacement, general use CVD Coated Cemented Carbide Grade Description Equivalentto ISO YC1015 MT-CVD coated, the substrate with exce lent wear resistance in com bination with MT-TiCN, fine grained AL 2 O 3 TiN multi-layer coating, which is suitable for finishing of steel. PO5~P15 YC1025 MT-CVD c...
1. Made from 100% virgin raw material; 2. Produced with advanced equipments and process; 3. All products go through in-process and final inspection; 4. Free online technical service available; 5. Stable and continuous production ability. PVD Coated Cemented Carbide Grade Description YP3015 2-4um TiALN PVDcoated, combinating with fine particles' substrates with high-toughness, suitabe for all materials, high-temperatu...
Dimension TYPE Dimensions (mm) b r l d t MGMN150-G 1.5 0.15 16 1.2 3.5 MGMN200-M 2 0.2 16 1.6 3.5 MGMN300-M 3 0.4 21 2.35 4.8 MGMN400-M 4 0.4 21 3.3 4.8 MGMN500-M 5 0.8 26 4.1 5.8 MGMN600-M 6 0.8 26 5 5.8 Grades Description CVD coated cemented carbide Grade Description Equivalent to ISO YC1015 MT-CVD coated, the substrate with excellent wear resistance in combination with MT-TiCN,fine grained AL2O3TiN multi-layer coa...
Tell us the grade, size and quantity you need, our engineers will reply with the best price within 24 hours.
Tell us the model, grade and quantity — our engineers reply with pricing within 24 hours.
